PRODUCT VIEW G1136-1600WNA product image 1

Images are for reference only. Actual product appearance may vary.

01 / 06

G1136-1600WNA

G1136

INQUIRY READY

G1136-1600WNA

Gospower / AC/DC Platinum / G1136

G1136-1600WNA applies 1600W capacity across Enterprise Servers, Storage Arrays, Network Equipment, and Data Center Racks; the result is predictable operation in continuous-duty installations.

Output Power (W):
1600
Length (mm):
185
Width (mm):
73.5
Height (mm):
40
Request a Quote ↗

Need compatibility confirmation? Send us your model, label photo, power rating, and connector requirements.

PRODUCT OVERVIEW

Built for reliable, continuous power delivery.

The G1136-1600WNA is suitable for infrastructure platforms that require very high power density, stable 12V output, and serviceable CRPS integration. Its 1600W capacity makes it a strong fit for enterprise servers, dense storage arrays, high-speed network systems, accelerator-based platforms, and data center environments where uptime, thermal control, and power stability are critical. Backplane pinout, control signaling, and mechanical retention should be checked together before the unit is approved for production use. Installation planning should account for ambient temperature, pressure drop, service access, and the electrical limits of the surrounding platform. System validation should cover standby behavior, load transitions, protection recovery, and monitoring compatibility under expected operating conditions.

Before integrating the G1136-1600WNA, confirm the mating connector or backplane, input source, output-rail requirements, hot-swap sequence, airflow direction, monitoring interface, redundancy behavior, and service clearance against the target platform.

CORE ADVANTAGES

1600W High-Power CRPS PSU for Enterprise Servers and Storage

1600W Power for Mission-Critical Infrastructure The G1136-1600WNA is designed for enterprise servers, high-density storage systems, networking equipment, and performance-focused infrastructure that require strong power delivery in a compact CRPS format.

01

1600W Power for Mission-Critical Infrastructure The G1136-1600WNA is designed for enterprise servers, high-density storage systems, networking equipment, and performance-focused infrastructure that require strong power delivery in a compact CRPS format.

02

Compact 1U CRPS Mechanical Design With a 185 × 73.5 × 40 mm form factor, this model supports dense rack integration where power density, hot-swap serviceability, and efficient airflow planning are essential.

03

Wide AC and DC Input Compatibility It supports 90–264Vac AC input and 180–300Vdc DC input, allowing flexible deployment across global data centers, enterprise server rooms, telecom cabinets, and distributed infrastructure sites.

04

High-Current 12V Output Performance The unit provides a 12V main output at 133.3A and a 12V standby output at 2.1A, supporting processors, storage backplanes, high-speed network cards, fans, accelerators, and management circuits.

05

Digital Power Control with PMBus Monitoring With PMBus 1.2 communication, the G1136-1600WNA enables compatible systems to monitor operating status, power conditions, fault signals, and system-level power behavior.

06

Built for Efficient and Reliable Operation Active PFC, intelligent fan control, reverse airflow capability, and support for UL, CE, FCC, CB, and CCC certifications help this model support mission-critical infrastructure with stable long-term performance.

MODEL SELECTION

Compare Gospower power options.

Review nearby Gospower models and select the power level, output architecture, efficiency grade, and form factor that best match the target system.

Model Power Output Current Efficiency Form Factor Recommended Use
G1136-0550WNA 550W 12V Platinum CRPS Enterprise servers and mixed workloads
G1136-0800WNA 800W 12V Platinum CRPS Storage systems and entry AI nodes
G1136-1200WNA 1200W 12V Platinum CRPS Dense compute and performance servers
G1136-1300WNA 1300W 12V Platinum CRPS High-concurrency compute and I/O platforms
G1136-1600WNA 1600W 12V Platinum CRPS Compute-heavy servers and expansion systems

DEPLOYMENT SCENARIOS

Where G1136-1600WNA fits best.

The G1136-1600WNA is suitable for infrastructure platforms that require very high power density, stable 12V output, and serviceable CRPS integration. Its 1600W capacity makes it a strong fit for enterprise servers, dense storage arrays, high-speed network systems, accelerator-based platforms, and data center environments where uptime, thermal control, and power stability are critical.

Scenario System Requirement Why G1136-1600WNA Fits
Enterprise Servers Strong power support for processors, memory, fans, and continuous workload cycles 1600W capacity provides high operating headroom for business-critical compute systems
High-Density Storage Arrays Reliable output for controllers, backplanes, drive groups, and cooling systems 133.3A 12V output supports storage-heavy platforms with demanding subsystem loads
Performance Network Systems Stable power for switches, routers, security gateways, and high-speed interfaces High-current delivery supports always-on network infrastructure and traffic-heavy operation
Accelerated Compute Platforms Power support for CPUs, accelerators, add-on cards, and thermal components Strong 12V capacity helps manage changing accelerator and compute load profiles
Data Center Rack Systems Compact power delivery for scalable rack-mounted infrastructure CRPS form factor supports high power density while maintaining service accessibility
Mission-Critical IT Equipment Reliable power for systems requiring uptime, monitoring, and service planning PMBus visibility and hot-swap-ready integration support maintenance and fault response

POWER DESIGN

Reliability notes for continuous operation.

The G1136-1600WNA is built for systems that require maximum power density within a compact CRPS 1U platform. Its 1600W output and 133.3A 12V main rail provide strong power support for enterprise compute, storage, network, and accelerator-based systems operating under demanding conditions.

  • 1600W output capacity supports enterprise servers, dense storage arrays, network systems, accelerator platforms, and mission-critical infrastructure.
  • 12V main output at 133.3A provides high-current power for system boards, processors, storage devices, network modules, fans, and control circuits.
  • Active PFC helps improve input power quality and supports efficient conversion under different AC power conditions.
  • Wide AC/DC input support allows use in data centers, telecom cabinets, enterprise racks, and global infrastructure environments.
  • PMBus 1.2 communication provides visibility into voltage, current, operating status, and fault information in supported systems.
  • Intelligent fan control adjusts cooling performance according to load changes and internal temperature conditions.
  • Reverse airflow capability supports alternative chassis airflow directions and customized rack cooling layouts.
  • Protection functions such as OVP, OCP, OTP, and SCP help reduce electrical and thermal risk during abnormal operating conditions.

INSTALLATION

Installation and operating guidance.

Confirm electrical compatibility, thermal clearance, mechanical fit, redundancy requirements, and system load before integration.

Installation / Operation Item Guidance
Load Planning Review total system demand from processors, storage devices, network modules, accelerators, fans, and management boards before deployment
Chassis Fitment Confirm the 185 × 73.5 × 40 mm CRPS form factor before mechanical integration
Input Connection Use within the supported 90–264Vac or 180–300Vdc input range
Power Headroom Leave reasonable margin for peak compute loads, drive activity, accelerator demand, and network traffic bursts
Airflow Direction Match standard or reverse airflow with the chassis cooling layout
Thermal Clearance Keep the PSU inlet, exhaust path, and surrounding airflow channels unobstructed
Monitoring Setup Use PMBus 1.2 where supported for telemetry, fault alerts, and maintenance visibility
Service Inspection Inspect fan condition, connector seating, dust buildup, and airflow path during regular service intervals

FAQ

Frequently asked questions about G1136-1600WNA.

Key answers for specification matching, installation planning, and system integration.

What type of power supply is the G1136-1600WNA?

The G1136-1600WNA is a 1600W CRPS power supply designed for enterprise servers, high-density storage systems, networking equipment, and mission-critical IT infrastructure.

What is the size of this model?

This model uses a compact 1U CRPS form factor with a size of 185 × 73.5 × 40 mm, making it suitable for high-density rack-mounted systems.

What input voltage range does it support?

The G1136-1600WNA supports 90–264Vac AC input and 180–300Vdc DC input for flexible deployment across different infrastructure power environments.

What output does the G1136-1600WNA provide?

It provides a 12V main output at 133.3A and a 12V standby output at 2.1A for system operation, standby functions, and platform management.

Is this model suitable for enterprise servers and storage systems?

Yes. Its 1600W capacity and high-current 12V output make it suitable for enterprise servers, dense storage arrays, and high-demand rack systems.

Does the G1136-1600WNA support PMBus monitoring?

Yes. The unit supports PMBus 1.2, allowing compatible platforms to monitor operating status, power conditions, and fault information.

Can this model support reverse airflow?

Yes. Reverse airflow capability is available for chassis designs that require an alternative PSU cooling direction.

What certifications can this model support?

The G1136-1600WNA can support UL, CE, FCC, CB, and CCC certifications for safety and EMC compliance in global server and infrastructure applications.
