HKS1300D1 1300W Titanium 12V CRPS Power Supply

CORE ADVANTAGES

1300W CRPS Titanium Power Supply for Efficient Enterprise Server Platforms

The HKS1300D1 provides 1300W output for enterprise servers, storage servers, business application platforms, virtualization nodes, and data center systems that require efficient 12V power delivery in a compact CRPS power module.

1300W Titanium CRPS Capacity

Titanium-Level Efficiency Design

Certified by 80 PLUS® Titanium , this model delivers peak efficiency exceeding 96% , with strong efficiency performance across practical server load conditions to help reduce power loss and heat generation.

Compact 1U CRPS Structure

Built in a standard 185 × 73.5 × 40 mm CRPS form factor, this model is suitable for 1U/2U rack server chassis where PSU bay space, airflow planning, and hot-swap serviceability are important.

Wide Input Compatibility

It supports 90–264Vac AC input , 47–63Hz frequency range, and 240Vdc input , making it suitable for enterprise server rooms, data center racks, and DC-supported infrastructure environments.

Reliable 12V Output Performance

The unit delivers up to 108.4A on the +12V main output under 230Vac input conditions, together with a +12VSB standby output up to 2.1A for standby control and system management functions.

Built for High-Efficiency Server Deployment

N+1 redundancy, cold backup, hot-swappable capability, black-box fault logging, online upgrade support, forced air cooling, high power factor, low harmonic distortion, and multiple protection functions help support stable operation in enterprise server environments.

MODEL SELECTION

Compare Huntkey power options.

Review nearby Huntkey models and select the output level and form factor that best match the target system.

Product Category	Model	Power	Output Current	Efficiency	Form Factor	Best-Fit Application
CRPS 12V Platinum	HKS360A1-CN	360W	12V / 30A	Platinum	CRPS	Compact servers, industrial PCs, and embedded control platforms
CRPS 12V Platinum	HK2400B-S1	2400W	12V / 195A	Platinum+	CRPS	General-purpose servers, storage servers, and AI server platforms
CRPS 12V Platinum	HK2000B-S1	2000W	12V / 164A	Platinum+	CRPS	High-density compute, storage, and data center systems
CRPS 12V Platinum	HK1600B-S1	1600W	12V / 132A	Platinum+	CRPS	Enterprise servers, virtualization hosts, and medium-density storage systems
CRPS 12V Platinum	HK1300B-S1	1300W	12V / 108A	Platinum+	CRPS	Standard 1U/2U servers, business applications, and enterprise IT platforms
CRPS 12V Platinum	HK800B-S1	800W	12V / 65A	Platinum+	CRPS	Network servers, industrial PCs, compact storage, and edge systems
CRPS 12V Platinum	HK550B-S1	550W	12V / 45A	Platinum+	CRPS	Edge gateways, compact network systems, industrial control, and security equipment
CRPS 12V Platinum	HKS2000C1-LP	2000W	12V / 164A	Platinum	CRPS	All-domestic high-power servers, storage systems, and AI server platforms
CRPS 12V Platinum	HKS1300C1-LP	1300W	12V / 108A	Platinum	CRPS	All-domestic enterprise servers, storage systems, and localized rack platforms
CRPS 12V Titanium	HKS3200D1-P	3200W	12V / 262A	Titanium+	CRPS	AI training servers, GPU compute platforms, and HPC clusters
CRPS 12V Titanium	HKS2700D1-P	2700W	12V / 221.6A	Titanium+	CRPS	High-density AI servers, cloud compute nodes, and accelerator platforms
CRPS 12V Titanium	HKS3600D1	3600W	12V / 295.1A	Titanium	CRPS	Extreme-density AI servers, GPU clusters, and high-power data center systems
CRPS 12V Titanium	HKS3200D1	3200W	12V / 262A	Titanium	CRPS	High-performance AI servers, HPC nodes, and cloud data center platforms
CRPS 12V Titanium	HKS2700D1	2700W	12V / 221.6A	Titanium	CRPS	Cloud compute nodes, GPU-assisted servers, and high-density storage platforms
CRPS 12V Titanium	HKS2000D1	2000W	12V / 164A	Titanium	CRPS	Efficient enterprise servers, storage servers, and AI inference platforms
CRPS 12V Titanium	HKS1300D1	1300W	12V / 108.4A	Titanium	CRPS	Efficient enterprise servers, business systems, and compact data center platforms

DEPLOYMENT SCENARIOS

Where HKS1300D1 fits best.

The HKS1300D1 is designed for enterprise server systems that need efficient 12V output, Titanium-level conversion performance, compact CRPS installation, and hot-swappable redundancy. It fits business application servers, enterprise storage systems, virtualization nodes, private cloud platforms, database servers, and standard data center racks where efficiency, reliability, and serviceability are important.

Scenario	System Requirement	Why HKS1300D1 Fits
Business Application Servers	Reliable power for ERP, CRM, office platforms, and internal enterprise systems	1300W output supports standard business workloads with efficient 12V delivery
Enterprise Storage Systems	Stable power for drives, controllers, expanders, and cooling modules	+12V output up to 108.4A supports storage hardware and system fans
Virtualization Nodes	Compact rack deployment with moderate compute and memory expansion	Titanium efficiency and 1300W capacity support long-hour virtualized workloads
Private Cloud Platforms	Efficient power support for scalable enterprise computing resources	CRPS hot-swap design improves serviceability in private cloud environments
Database Servers	Continuous power delivery for processors, memory, storage, and cooling	Stable 12V output supports data-intensive enterprise applications
Redundant Rack Systems	Backup power design and easier PSU module replacement	N+1 redundancy with 0≤N≤3 and hot-swap support improve power availability

POWER DESIGN

Reliability notes for continuous operation.

The HKS1300D1 focuses on high-efficiency 12V power delivery for enterprise servers, storage systems, virtualization platforms, and standard data center infrastructure. It provides 1300W output in a standard 185 × 73.5 × 40 mm CRPS structure, making it suitable for systems that need better efficiency than Platinum-level options while keeping compact installation and practical power headroom.

1300W output rating supports enterprise servers, business application systems, storage servers, virtualization nodes, and private cloud platforms.
Under 110Vac input, the +12V rail supports up to 66.7A; under 230Vac input, it supports up to 108.4A.
+12VSB standby output supports 0.1A to 2.1A, providing auxiliary power for standby control and system management.
Efficiency performance reaches ≥90% at 10% load, ≥94% at 20% load, ≥96% at 50% load, and ≥93.5% at 100% load.
The unit supports N+1 redundancy with 0≤N≤3, helping compatible systems build high-availability power architectures.
Black-box fault logging helps maintenance teams review abnormal power events and operating history.
Online upgrade capability supports system-level service and long-term platform maintenance.
Protection functions include input undervoltage, input overvoltage, input current limiting, output overvoltage, output overcurrent, output short circuit, and overtemperature protection.

INSTALLATION

Installation and operating guidance.

The HKS1300D1 is designed for forced air cooling and has an MTBF value of 200,000 H. For storage and transportation, it supports an air temperature range of -40°C to 70°C and relative humidity of 5%–100%. EMI performance is listed as EN55032 Class A, and ground leakage current is <3.5mA at 240V RMS. Safety standards include CE, CB, FCC, UL, TUV, LVD, CQC, and 80 Plus.

Installation / Operation Item	Guidance
Load Planning	Match the system power budget with the actual input condition, especially when using 110Vac or 230Vac input
Input Connection	Use within the supported 90–264Vac input range or supported 240Vdc environment
Output Matching	Confirm that the server platform can safely use the available +12V output current under the selected input condition
Chassis Fitment	Confirm the 185 × 73.5 × 40 mm CRPS size before integrating the PSU into the server chassis
Redundant System Use	Use N+1 redundancy and hot-swap functions only with compatible power shelves, backplanes, and system control logic
Thermal Clearance	Keep intake and exhaust areas open to support forced air cooling during continuous operation
Operating Environment	Keep air temperature within 0–55°C and relative humidity within 5%–95%, with no condensation
Routine Maintenance	Check fan condition, dust buildup, connector seating, fault logs, and hot-swap operation during regular service

FAQ

Frequently asked questions about HKS1300D1.

Key answers for specification matching, installation planning, and system integration.

What type of power supply is the HKS1300D1?

The HKS1300D1 is a 1300W CRPS 12V Titanium power supply designed for enterprise servers, storage systems, virtualization nodes, private cloud platforms, and standard data center environments.

What is the size of this model?

It uses a standard CRPS structure with a size of 185 × 73.5 × 40 mm , making it suitable for 1U/2U rack server chassis and compact data center platforms.

What input voltage range does it support?

The HKS1300D1 supports 90–264Vac AC input , 47–63Hz , and also supports 240Vdc input for compatible infrastructure environments.

What output does the HKS1300D1 provide?

It provides a +12V main output up to 108.4A under 230Vac input , together with a +12VSB standby output up to 2.1A .

Is this model suitable for enterprise servers?

Yes. Its 1300W capacity, Titanium efficiency, and compact CRPS structure make it suitable for enterprise servers, business application systems, and private cloud nodes.

How does the output current differ between 110Vac and 230Vac input?

Under 110Vac input , the +12V output supports up to 66.7A . Under 230Vac input , it supports up to 108.4A , so system load planning should match the actual input environment.

What efficiency performance does this Titanium model provide?

It reaches ≥96% efficiency at 50% load and ≥93.5% at 100% load , helping reduce power loss and thermal pressure in long-hour server operation.

Does this model support hot swapping and redundancy?

Yes. It supports hot-swappable operation and N+1 redundancy with 0≤N≤3 , helping compatible systems improve power availability and maintenance flexibility.

HKS1300D1

Built for reliable, continuous power delivery.
