PRODUCT VIEW CRPS2400D2 product image 1

Images are for reference only. Actual product appearance may vary.

01 / 06

CRPS2400D2

CRPS

INQUIRY READY

CRPS2400D2

Greatwall / Server Power Supply / CRPS

CRPS2400D2 gives Data Center Servers, Cloud Computing Nodes, Storage Platforms, and AI/Hpc Systems a power platform built around 2400W capacity and a stable +12V / 91A rail. It is intended for controlled delivery for equipment expected to run for long periods.

Model
CRPS2400D2
Input Voltage
90VAC–264VAC or 180VDC–320VDC
Standby Output
+12VSB / 3A
Output Power
2400W
Request a Quote ↗

Need compatibility confirmation? Send us your model, label photo, power rating, and connector requirements.

PRODUCT OVERVIEW

Built for reliable, continuous power delivery.

The CRPS2400D2 is designed for server and infrastructure systems that require higher power capacity than 2200W-class CRPS units while still maintaining a compact mechanical footprint. It is suitable for high-density server platforms, cloud computing nodes, storage systems, AI/HPC infrastructure, and enterprise environments where strong 12V output, efficiency, and thermal reliability are important.

Plan the CRPS2400D2 output wiring around the actual current demand: keep conductors short, use low-resistance terminations, separate power paths from sensitive signal wiring, and preserve access for retightening and inspection. Arrange the enclosure so heat from neighboring components cannot collect around the supply or its connection points.

Qualify the CRPS2400D2 at several load levels, measuring voltage at both the supply terminals and the equipment input rather than relying only on no-load readings. Record cable drop, connector temperature, and enclosure temperature as baseline values. Later maintenance checks can compare against this record to identify loose joints, rising contact resistance, or deteriorating heat dissipation before they interrupt service.

CORE ADVANTAGES

2400W CRPS Power Supply for High-Density Server, Cloud, and Advanced Infrastructure Platforms

The CRPS2400D2 delivers 2400W output for high-density servers, cloud computing nodes, storage systems, and advanced infrastructure platforms requiring strong and stable 12V power delivery.

01

2400W High-Capacity CRPS Power Output

The CRPS2400D2 delivers 2400W output for high-density servers, cloud computing nodes, storage systems, and advanced infrastructure platforms requiring strong and stable 12V power delivery.

02

Compact 185 × 73.5 × 40 mm CRPS Structure

Built in a standard 185 × 73.5 × 40 mm CRPS form factor, this model provides high power density while maintaining compatibility with compact server chassis and rack-mounted systems.

03

Wide AC and DC Input Compatibility

It supports 90VAC–264VAC AC input and 180VDC–320VDC DC input , making it suitable for different data center power environments, rack systems, and enterprise infrastructure designs.

04

Multiple High-Current 12V Output Options

The unit provides +12V / 91A , +12V / 181A , and +12V / 197A main output configurations, together with +12VSB / 3A standby output for system control and standby operation.

05

Platinum Efficiency for Continuous Operation

With Platinum efficiency , the CRPS2400D2 helps reduce power conversion loss, improve energy utilization, and support better thermal performance in 24/7 server environments.

06

Reliable Certification Coverage for Global Deployment

With certifications including CE, CQC, IRAM, TUV, UKCA, and UL , this model supports reliable deployment in data centers, enterprise servers, cloud systems, and high-performance computing platforms.

MODEL SELECTION

Compare Greatwall power options.

Review nearby Greatwall models and select the power level, output architecture, and form factor that best match the target system.

Model Power Input Voltage Efficiency Form Factor Best-Fit Application
CRPS2200D2 2200W 90VAC–264VAC or 180VDC–320VDC Platinum CRPS High-density servers, advanced compute nodes, and demanding 12V infrastructure platforms
CRPS2400D2 2400W 90VAC–264VAC or 180VDC–320VDC Platinum CRPS Higher-load cloud, storage, and enterprise server systems requiring stronger current headroom
CRPS2700D2 2700W 90VAC–264VAC or 180VDC–320VDC Platinum CRPS Ultra-high-density data center, AI, HPC, and advanced infrastructure platforms with heavier expansion demand

DEPLOYMENT SCENARIOS

Where CRPS2400D2 fits best.

The CRPS2400D2 is designed for server and infrastructure systems that require higher power capacity than 2200W-class CRPS units while still maintaining a compact mechanical footprint. It is suitable for high-density server platforms, cloud computing nodes, storage systems, AI/HPC infrastructure, and enterprise environments where strong 12V output, efficiency, and thermal reliability are important.

Scenario System Requirement Why CRPS2400D2 Fits
Data Center Servers High-capacity power for mission-critical rack-mounted servers 2400W output supports demanding compute loads, expansion cards, system boards, and cooling components
Cloud Computing Nodes Stable 12V delivery for scalable virtualized infrastructure Platinum efficiency helps reduce energy loss in large-scale server deployments
Storage Platforms Reliable power for controllers, backplanes, drives, and cooling modules Multiple high-current 12V output options support storage systems with heavier current demand
AI / HPC Systems Strong power headroom for advanced compute and accelerator-supported workloads 2400W capacity provides practical support for CPU, GPU, and expansion-heavy configurations
Enterprise Infrastructure Continuous 24/7 operation for business-critical platforms Wide AC/DC input range supports deployment across different rack and power distribution environments
Advanced Network Equipment Stable power for high-throughput network and processing platforms High 12V current capacity supports heavier I/O, processors, and system-level hardware loads

POWER DESIGN

Reliability notes for continuous operation.

The CRPS2400D2 is built for high-density server platforms where strong 12V power delivery, compact installation, and long-term operating reliability are required. Compared with 2200W CRPS models, it provides additional power headroom for server systems with heavier compute, storage, networking, and expansion requirements.

  • 2400W output capacity supports high-density servers, cloud platforms, storage systems, and advanced infrastructure equipment.
  • Multiple 12V main output configurations provide flexibility for different server power architectures and load requirements.
  • +12VSB / 3A standby output supports system standby control, management logic, and auxiliary circuit functions.
  • Platinum efficiency helps reduce energy loss and supports improved thermal performance during continuous operation.
  • Wide AC/DC input support allows the unit to adapt to different data center, rack, and cabinet power environments.
  • FR airflow direction supports standard front-to-rear cooling designs commonly used in server chassis.
  • Compact CRPS form factor allows high power density without requiring a larger mechanical footprint.
  • Certification coverage helps support safer and more reliable use in enterprise, data center, and international infrastructure projects.

INSTALLATION

Installation and operating guidance.

Confirm electrical compatibility, thermal clearance, mechanical fit, and system load before integration.

Installation / Operation Item Guidance
Load Planning Keep long-term operating load within a suitable range to support stable output, efficiency, and service life
Chassis Fitment Confirm the system supports the 185 × 73.5 × 40 mm CRPS form factor before installation
Input Verification Use the power supply within the supported 90–264VAC or 180–320VDC input range
Output Matching Confirm that the server platform supports the required 12V output configuration and standby power demand
Airflow Direction Make sure the FR airflow direction matches the chassis cooling path before deployment
Thermal Clearance Keep intake and exhaust areas open to avoid heat accumulation around the PSU bay
Module Installation Ensure the power module is fully seated and correctly connected before powering on the server
Routine Maintenance Check fan condition, dust buildup, connector status, and system thermal behavior during regular maintenance

FAQ

Frequently asked questions about CRPS2400D2.

Key answers for specification matching, installation planning, and system integration.

What type of power supply is the CRPS2400D2?

The CRPS2400D2 is a 2400W CRPS server power supply designed for high-density servers, cloud computing nodes, storage systems, AI/HPC platforms, and advanced infrastructure equipment.

What is the size of this model?

It uses a compact CRPS structure with dimensions of 185 × 73.5 × 40 mm.

What input voltage range does it support?

The CRPS2400D2 supports 90VAC–264VAC AC input and 180VDC–320VDC DC input.

What output does the CRPS2400D2 provide?

It provides +12V / 91A, +12V / 181A, and +12V / 197A main output configurations, together with +12VSB / 3A standby output.

Is this model suitable for high-density cloud and storage platforms?

Yes. Its 2400W output capacity and multiple high-current 12V output options make it suitable for cloud nodes, dense storage systems, and enterprise server platforms with heavier power requirements.

What airflow direction does this model support?

The CRPS2400D2 supports FR airflow, which is suitable for standard front-to-rear cooling layouts in server chassis.

What efficiency level does this power supply offer?

The CRPS2400D2 is rated at Platinum efficiency, helping reduce power conversion loss and improve energy utilization in continuous server operation.

What certifications are listed for this model?

The listed certifications include CE, CQC, IRAM, TUV, UKCA, and UL.
