PRODUCT VIEW CRPS2700D2 product image 1

Images are for reference only. Actual product appearance may vary.

01 / 06

CRPS2700D2

CRPS

INQUIRY READY

CRPS2700D2

Greatwall / Server Power Supply / CRPS

CRPS2700D2 matches Data Center Servers, Cloud Computing Nodes, Storage Platforms, and AI/Hpc Systems with 2700W capacity and a stable +12V / 98.4A rail, helping operators achieve an installation-ready choice for mission-critical equipment.

Model
CRPS2700D2
Input Voltage
90VAC–264VAC or 180VDC–320VDC
Standby Output
+12VSB / 3A
Output Power
2700W
Request a Quote ↗

Need compatibility confirmation? Send us your model, label photo, power rating, and connector requirements.

PRODUCT OVERVIEW

Built for reliable, continuous power delivery.

The CRPS2700D2 is designed for server systems that require very high power density in a compact CRPS mechanical format. It fits data center servers, cloud infrastructure, storage platforms, AI/HPC systems, and advanced enterprise equipment where strong 12V output, flexible airflow, high efficiency, and long-term reliability are important. For this 2700W capacity, +12V / 98.4A, +12V / 205A, +12V / 221.4A output, for long-term service, document fan inspection, connector seating, event-log review, and replacement procedures as part of the maintenance plan. Commissioning should verify grounding, input protection, output stability, and the response of any redundant or hot-swap control logic.

Plan the CRPS2700D2 output wiring around the actual current demand: keep conductors short, use low-resistance terminations, separate power paths from sensitive signal wiring, and preserve access for retightening and inspection. Arrange the enclosure so heat from neighboring components cannot collect around the supply or its connection points.

Qualify the CRPS2700D2 at several load levels, measuring voltage at both the supply terminals and the equipment input rather than relying only on no-load readings. Record cable drop, connector temperature, and enclosure temperature as baseline values. Later maintenance checks can compare against this record to identify loose joints, rising contact resistance, or deteriorating heat dissipation before they interrupt service.

CORE ADVANTAGES

2700W CRPS Power Supply for Ultra-High-Density Server and AI Infrastructure Platforms

The CRPS2700D2 delivers 2700W output for high-density servers, AI computing systems, cloud infrastructure, storage platforms, and advanced data center equipment requiring stronger 12V power delivery.

01

2700W Ultra-High-Density CRPS Power Capacity

The CRPS2700D2 delivers 2700W output for high-density servers, AI computing systems, cloud infrastructure, storage platforms, and advanced data center equipment requiring stronger 12V power delivery.

02

Compact 185 × 73.5 × 40 mm CRPS Structure

Built in a compact 185 × 73.5 × 40 mm CRPS form factor, this model provides high power density while maintaining compatibility with space-limited server chassis and rack systems.

03

Wide AC and DC Input Compatibility

It supports 90VAC–264VAC AC input and 180VDC–320VDC DC input , making it suitable for different data center power architectures, rack power systems, and enterprise infrastructure environments.

04

Multiple High-Current 12V Output Options

The unit provides +12V / 98.4A , +12V / 205A , and +12V / 221.4A main output configurations, together with +12VSB / 3A standby output for system control and standby operation.

05

Platinum Efficiency for Demanding 24/7 Workloads

With Platinum efficiency , the CRPS2700D2 helps reduce energy loss, improve conversion performance, and support better thermal control in continuous high-load server environments.

06

Flexible Airflow and Broad Certification Coverage

With FR or RF airflow direction and certifications including UL, CE, FCC, 80 PLUS, CQC, BSMI, KC, TUV, EAC, RCM, BIS, IRAM, Morocco, Ukraine, and UKCA , this model supports flexible deployment across global server and infrastructure projects.

MODEL SELECTION

Compare Greatwall power options.

Review nearby Greatwall models and select the power level, output architecture, and form factor that best match the target system.

Model Power Input Voltage Efficiency Form Factor Best-Fit Application
CRPS2200D2 2200W 90VAC–264VAC or 180VDC–320VDC Platinum CRPS High-density servers, advanced compute nodes, and demanding 12V infrastructure platforms
CRPS2400D2 2400W 90VAC–264VAC or 180VDC–320VDC Platinum CRPS Higher-load cloud, storage, and enterprise server systems requiring stronger current headroom
CRPS2700D2 2700W 90VAC–264VAC or 180VDC–320VDC Platinum CRPS Ultra-high-density data center, AI, HPC, and advanced infrastructure platforms with heavier expansion demand

DEPLOYMENT SCENARIOS

Where CRPS2700D2 fits best.

The CRPS2700D2 is designed for server systems that require very high power density in a compact CRPS mechanical format. It fits data center servers, cloud infrastructure, storage platforms, AI/HPC systems, and advanced enterprise equipment where strong 12V output, flexible airflow, high efficiency, and long-term reliability are important.

Scenario System Requirement Why CRPS2700D2 Fits
Data Center Servers High-capacity power for mission-critical rack-mounted servers 2700W output supports heavier compute loads, high-current boards, and expansion components
Cloud Computing Nodes Stable 12V delivery for large-scale distributed infrastructure Platinum efficiency helps reduce power loss across dense server deployments
Storage Platforms Reliable power for controllers, backplanes, drives, and cooling modules Multiple 12V output options support storage systems with higher current demand
AI / HPC Systems Strong power headroom for accelerator-supported workloads 2700W capacity supports CPU, GPU, accelerator, and mixed compute configurations
Enterprise Infrastructure Continuous 24/7 operation for business-critical platforms Wide AC/DC input range supports flexible deployment in different server room environments
Advanced Network Equipment Stable power for high-throughput processing and network platforms High 12V current capacity supports heavier I/O, processor, and cooling requirements

POWER DESIGN

Reliability notes for continuous operation.

The CRPS2700D2 is built for ultra-high-density server platforms where strong 12V output capacity, compact mechanical design, flexible airflow, and reliable continuous operation are essential. Compared with 2200W and 2400W CRPS models, it provides higher power headroom for systems with heavier compute, storage, networking, and accelerator requirements.

  • 2700W output capacity supports dense server systems, AI infrastructure, cloud platforms, storage equipment, and advanced compute nodes.
  • Multiple high-current 12V output configurations provide flexibility for different server platform architectures and load requirements.
  • +12VSB / 3A standby output supports system standby logic, management functions, and auxiliary control circuits.
  • Platinum efficiency helps reduce power conversion loss and supports better thermal behavior during continuous operation.
  • Wide AC/DC input support allows the power supply to adapt to different rack, cabinet, and data center power environments.
  • FR or RF airflow options help match different chassis cooling layouts and system thermal directions.
  • Compact CRPS structure enables high power density without requiring a larger power supply footprint.
  • Broad certification coverage supports wider deployment across enterprise, data center, and international infrastructure projects.

INSTALLATION

Installation and operating guidance.

Confirm electrical compatibility, thermal clearance, mechanical fit, and system load before integration.

Installation / Operation Item Guidance
Load Planning Keep long-term operating load within a suitable range to support stable output, efficiency, and service life
Chassis Fitment Confirm the system supports the 185 × 73.5 × 40 mm CRPS form factor before installation
Input Verification Use the power supply within the supported 90–264VAC or 180–320VDC input range
Output Matching Confirm that the server platform supports the required 12V output configuration and standby power demand
Airflow Selection Select FR or RF airflow according to the chassis cooling direction and system thermal design
Thermal Clearance Keep intake and exhaust areas open to avoid heat buildup around the PSU bay
Module Installation Ensure the power module is fully seated and correctly connected before powering on the server
Routine Maintenance Check fan condition, dust accumulation, connector status, and system thermal behavior during regular service

FAQ

Frequently asked questions about CRPS2700D2.

Key answers for specification matching, installation planning, and system integration.

What type of power supply is the CRPS2700D2?

The CRPS2700D2 is a 2700W CRPS server power supply designed for high-density servers, cloud computing nodes, storage systems, AI/HPC platforms, and advanced infrastructure equipment.

What is the size of this model?

It uses a compact CRPS structure with dimensions of 185 × 73.5 × 40 mm.

What input voltage range does it support?

The CRPS2700D2 supports 90VAC–264VAC AC input and 180VDC–320VDC DC input.

What output does the CRPS2700D2 provide?

It provides +12V / 98.4A, +12V / 205A, and +12V / 221.4A main output configurations, together with +12VSB / 3A standby output.

Is this model suitable for AI and HPC server platforms?

Yes. Its 2700W output capacity and high-current 12V output options make it suitable for AI servers, HPC systems, accelerator-supported platforms, and other demanding compute environments.

Does the CRPS2700D2 support different airflow directions?

Yes. The CRPS2700D2 supports FR or RF airflow, making it easier to match different chassis cooling layouts.

What efficiency level does this power supply offer?

The CRPS2700D2 is rated at Platinum efficiency, helping reduce power conversion loss and improve energy utilization in continuous server operation.

What certifications are listed for this model?

The listed certifications include UL, CE, FCC, 80 PLUS, CQC, BSMI, KC, TUV, EAC, RCM, BIS, IRAM, Morocco, Ukraine, and UKCA.
