PRODUCT VIEW GW-TO150WV54 product image 1

Images are for reference only. Actual product appearance may vary.

01 / 06

GW-TO150WV54

Open Frame

INQUIRY READY

GW-TO150WV54

Greatwall / Server Power Supply / Open Frame

GW-TO150WV54 brings together 150W capacity and a stable 54V rail for Telecom Systems, Communication Devices, Distributed DC Power Systems, and Industrial Control, with an emphasis on steady operation across always-on infrastructure.

Model
GW-TO150WV54
Series
Open Frame
Input Voltage
90-290Vac / 192-288Vdc
Output Voltage
54V
Request a Quote ↗

Need compatibility confirmation? Send us your model, label photo, power rating, and connector requirements.

PRODUCT OVERVIEW

Built for reliable, continuous power delivery.

GW-TO150WV54 is suitable for applications that need higher 54V power delivery in a compact internal power structure. It can be used in communication systems, PoE-related devices, industrial control platforms, embedded hardware, and OEM electrical equipment where stable DC power and flexible installation are important.

Plan the GW-TO150WV54 output wiring around the actual current demand: keep conductors short, use low-resistance terminations, separate power paths from sensitive signal wiring, and preserve access for retightening and inspection. Arrange the enclosure so heat from neighboring components cannot collect around the supply or its connection points.

Qualify the GW-TO150WV54 at several load levels, measuring voltage at both the supply terminals and the equipment input rather than relying only on no-load readings. Record cable drop, connector temperature, and enclosure temperature as baseline values. Later maintenance checks can compare against this record to identify loose joints, rising contact resistance, or deteriorating heat dissipation before they interrupt service.

CORE ADVANTAGES

150W Open Frame Power Supply

GW-TO150WV54 provides 150W output capacity in a board-level open frame structure. Compared with lower-power open frame models, it is more suitable for systems that require stronger output capability while still maintaining compact integration inside equipment enclosures.

01

150W Open Frame Power Capacity

GW-TO150WV54 provides 150W output capacity in a board-level open frame structure. Compared with lower-power open frame models, it is more suitable for systems that require stronger output capability while still maintaining compact integration inside equipment enclosures.

02

Stable 54V DC Output

The model delivers 54V output, making it suitable for communication devices, PoE-related equipment, distributed DC power systems, industrial terminals, and electronic platforms that require higher DC voltage instead of standard 12V output.

03

Wide AC/DC Input Support

With 90-290Vac / 192-288Vdc input capability, GW-TO150WV54 can support different power environments and installation conditions. This helps equipment manufacturers improve product adaptability across different markets and power infrastructure setups.

04

Safety Certification Support

GW-TO150WV54 lists CCC / CB / CE safety standards, providing compliance references for equipment manufacturers that need safety certification support for domestic and international applications.

05

Suitable for OEM Integration

The open frame design is suitable for manufacturers building customized equipment. It can be installed inside communication devices, control cabinets, embedded systems, network equipment, and industrial electronic platforms.

06

Power Headroom for Multi-Module Systems

The 150W rating provides more usable power capacity than the lower-power 54V models in this series. This makes it a practical choice for equipment containing multiple communication, control, interface, or auxiliary modules, provided the total load remains within the rated output.

MODEL SELECTION

Compare Greatwall power options.

Review nearby Greatwall models and select the power level, output architecture, and form factor that best match the target system.

Model Input Voltage Output Voltage Safety Watt Recommended Application
GW-TO25WV12 90-290Vac / 192-288Vdc 12V CCC / CB / CE 25W Small control boards, compact terminals, and low-power electronic devices
GW-TO40WV12 90-290Vac / 192-288Vdc 12V CCC / CB / CE 40W Compact 12V equipment, embedded controllers, and light-load industrial systems
GW-TO70WV12 90-290Vac / 192-288Vdc 12V CCC / CB / CE 70W Medium-low power 12V systems requiring wide input support and compact integration
GW-TO70WV54 90-290Vac / 192-288Vdc 54V CCC / CB / CE 70W Compact 54V systems, communication terminals, PoE-related devices, and distributed DC equipment
GW-TO150WV54 90-290Vac / 192-288Vdc 54V CCC / CB / CE 150W Higher-load 54V communication equipment, PoE power platforms, and industrial DC systems
GW-TO409WV12 90-290Vac / 190-290Vdc 54V CCC / CB / CE 409W High-load open frame systems requiring stronger power capacity and DC input flexibility
GW-TO460WV12 90-290Vac / 190-290Vdc 54V CCC / CB / CE 460W Higher-power industrial, embedded, and equipment-level power platforms

DEPLOYMENT SCENARIOS

Where GW-TO150WV54 fits best.

GW-TO150WV54 is suitable for applications that need higher 54V power delivery in a compact internal power structure. It can be used in communication systems, PoE-related devices, industrial control platforms, embedded hardware, and OEM electrical equipment where stable DC power and flexible installation are important.

Scenario Application Value
Communication Equipment Provides 54V DC output for gateways, terminals, signal devices, and communication control units
PoE-Related Systems Suitable for PoE switches, PoE modules, network power equipment, and distributed DC power designs
Industrial Control Platforms Supports automation terminals, control cabinets, industrial electronics, and field equipment
Embedded Systems Provides internal 54V power for embedded hardware platforms with higher load demand
OEM Electrical Equipment Helps manufacturers integrate a 150W 54V power module into customized enclosures and system assemblies

POWER DESIGN

Reliability notes for continuous operation.

GW-TO150WV54 is designed for equipment-level integration where 54V output, higher load capacity, and compact installation are required. Compared with 70W models, its 150W output gives system designers more power margin for communication equipment, PoE-related devices, and industrial platforms with multiple internal modules.

Design Point Recommendation
Load Planning Reserve enough power margin and avoid continuous full-load operation in high-temperature environments
Voltage Matching Confirm that the final equipment is designed for 54V input before installation
Thermal Management Provide sufficient airflow and keep heat-generating components away from blocked areas
Electrical Safety Maintain proper insulation, clearance, and creepage distance inside the final enclosure
Wiring Capacity Use suitable wire gauge and connector rating for the 150W output level
System Validation Test the complete equipment under real operating load before batch production

INSTALLATION

Installation and operating guidance.

Confirm electrical compatibility, thermal clearance, mechanical fit, and system load before integration.

Item Guidance
Installation Position Install inside a protected equipment enclosure, cabinet, or host system
Input Check Confirm AC/DC input conditions before powering on
Output Check Verify 54V output polarity and load compatibility before connection
Ventilation Keep airflow paths open and avoid covering heat-sensitive components
Mechanical Fixing Secure the PCB properly to reduce vibration, movement, and connector stress
Safety Protection Prevent direct user contact with exposed circuits after final assembly
Maintenance Check dust buildup, loose wiring, abnormal temperature, and component aging during regular service

FAQ

Frequently asked questions about GW-TO150WV54.

Key answers for specification matching, installation planning, and system integration.

What type of equipment is GW-TO150WV54 suitable for?

GW-TO150WV54 is suitable for communication equipment, PoE-related systems, industrial control devices, embedded platforms, and OEM equipment that require 54V DC output with 150W power capacity.

What is the difference between GW-TO150WV54 and GW-TO70WV54?

Both models provide 54V output, but GW-TO150WV54 offers 150W capacity, while GW-TO70WV54 offers 70W capacity. GW-TO150WV54 is better for systems with higher load demand.

Is GW-TO150WV54 an open frame power supply?

Yes. It is an open frame power supply designed for internal equipment integration. It should be installed inside a protected host enclosure or device housing.

What input voltage does this model support?

GW-TO150WV54 supports 90-290Vac / 192-288Vdc, making it suitable for wide AC input and compatible DC input environments.

Can this model be used for PoE-related equipment?

Yes. Its 54V output and 150W capacity make it suitable for many PoE-related systems, provided the final equipment power demand and electrical design match the specification.

What should be checked before installation?

Engineers should check input voltage, 54V load compatibility, total power consumption, wire rating, insulation distance, airflow, and final enclosure protection.

Is 150W enough for industrial control systems?

It depends on the total system load. For many medium-power industrial control devices, communication terminals, and embedded platforms, 150W can provide more margin than 70W models.

How should I choose between 12V and 54V Open Frame models?

Choose 12V models for standard control boards, embedded modules, and low-voltage electronics. Choose 54V models such as GW-TO150WV54 for communication equipment, PoE-related systems, and platforms designed for higher DC voltage.
